ELK is a bundle of three open-source software projects maintained by Elastic. Elastic has recently included a family of log shippers called Beats and renamed the stack as Elastic Stack. The solution is flexible and is mostly used to centralize logging requirements.

The ELK stack consists of:

• Elasticsearch, a NoSQL database based on the Lucene search engine.
• Logstash, a server-side data processing pipeline that accepts data from various sources simultaneously, transforms it, and exports the data to various targets.
• Kibana, a visualization layer that works on top of Elasticsearch.

Installing the ELK stack

1. Install Java. In this tutorial, we use the OpenJDK package.

   apt install -y openjdk-8-jdk
   Copy code

2. Install the Elastic GPG Key to validate the packages.

   wget -qO - https://artifacts.elastic.co/GPG-KEY-elasticsearch | apt-key add -
   Copy code

3. Install HTTPS transport to download the packages over a secure connection.

   apt install -y apt-transport-https
   Copy code

4. Add the Elastic repository to the APT configuration.

   echo "deb [signed-by=/usr/share/keyrings/elasticsearch-keyring.gpg] https://artifacts.elastic.co/packages/8.x/apt stable main" | sudo tee /etc/apt/sources.list.d/elastic-8.x.list
   Copy code

5. Update APT and install Elasticsearch.

   apt update && apt install -y elasticsearch
   Copy code

6. Uncomment and edit the following lines in the /etc/elasticsearch/elasticsearch.yml file to reflect the example below. This will limit the Elasticsearch connection to localhost.

   network.host: 127.0.0.1
   http.port:9200
   Copy code

7. Install Logstash and rsyslog.

   apt install -y logstash rsyslog
   Copy code

8. Install Filebeat.

   apt install -y filebeat
   Copy code

9. Install Kibana.

   apt install -y kibana
   Copy code

10. Start Elasticsearch:

    systemctl start elasticsearch
    Copy code

11. Run the following command to verify whether Elasticsearch is running:

    curl -X GET "localhost:9200"
    Copy code

    The output should be similar to this example:

    {
      "name" : "elastic-stack",
      "cluster_name" : "elasticsearch",
      "cluster_uuid" : "LiIyk5P1TMuR6MqOWcs_DQ",
      "version" : {
        "number" : "7.8.0",
        "build_flavor" : "default",
        "build_type" : "deb",
        "build_hash" : "757314695644ea9a1dc2fecd26d1a43856725e65",
        "build_date" : "2020-06-14T19:35:50.234439Z",
        "build_snapshot" : false,
        "lucene_version" : "8.5.1",
        "minimum_wire_compatibility_version" : "6.8.0",
        "minimum_index_compatibility_version" : "6.0.0-beta1"
      },
      "tagline" : "You Know, for Search"
    }
    Copy code

12. Open the file /etc/kibana/kibana.yml and uncomment the following lines:

    server.port: 5601
    server.host: "localhost"
    elasticsearch.hosts: ["http://localhost:9200"]
    Copy code

    Save and exit.

13. Enable and start the Kibana service in systemd:

    systemctl enable kibana
    systemctl start kibana
    Copy code

14. Install nginx as a proxy to Kibana:

    apt install -y nginx
    Copy code

15. Use OpenSSL to create a user and password for the Elastic Stack interface. This command generates a htpasswd file, containing the user kibana and a password you are prompted to create.

    echo "kibana:`openssl passwd -apr1`" | tee -a /etc/nginx/htpasswd.users
    Copy code

16. Edit the /etc/nginx/sites-available/elastic.local file and paste the following content to create a proxy to Kibana.

    Important:

    Replace elastic.local with the domain name of your Instance:

        server {
          listen 80;
          server_name elastic.local;

          auth_basic "Restricted Access";
          auth_basic_user_file /etc/nginx/htpasswd.users;

          location / {
            proxy_pass         http://localhost:5601;
            proxy_redirect     off;

            proxy_set_header   Host              $host;
            proxy_set_header   X-Forwarded-For   $proxy_add_x_forwarded_for;
            proxy_set_header   X-Forwarded-Proto $scheme;
          }

        }
    Copy code

17. Create a symbolic link to enable the site in nginx:

    ln -s /etc/nginx/sites-available/elastic.local /etc/nginx/sites-enabled/elastic.local
    Copy code

18. Reload the nginx configuration to activate the proxy:

    systemctl restart nginx
    Copy code

You can now access your Elastic Dashboard using your domain name, for example http://elastic.local:

You can either start with an empty stack and start collecting your metrics or load sample data.

Configuring rsyslog

Edit the file /etc/rsyslog.conf, uncomment the following lines and save.

# provides UDP syslog reception
module(load="imudp")
input(type="imudp" port="514")
Copy code

Configuring Logstash

Logstash allows you to collect data from different sources, transform it into a common format, and to export it to a defined destination.

Logstash configuration files are written in JSON and can be found in the /etc/logstash/conf.d directory.

1. Configure a Filebeat input in the configuration file 02-beats-input.conf:

   nano /etc/logstash/conf.d/02-beats-input.conf
   Copy code

   Copy the following information into the file, save and close it. This configuration allows the beats input to listen on port 5044:

   input {
     beats {
       port => 5044
     }
   }
   Copy code

2. Create a file named /etc/logstash/conf.d/10-syslog-filter.conf and paste the following contents.

   filter {
     if [type] == "syslog" {
       grok {
         match => { "message" => "%{SYSLOGTIMESTAMP:syslog_timestamp} %{SYSLOGHOST:syslog_hostname} %{DATA:syslog_program}(?:\[%{POSINT:syslog_pid}\])?: %{GREEDYDATA:syslog_message}" }
         add_field => [ "received_at", "%{@timestamp}" ]
         add_field => [ "received_from", "%{host}" ]
       }
       syslog_pri { }
       date {
         match => [ "syslog_timestamp", "MMM  d HH:mm:ss", "MMM dd HH:mm:ss" ]
       }
     }
   }
   Copy code

   Save and close.

   Note:

   This filter parses incoming system logs to make them structured and usable by the Kibana Dashboards. For more information refer to the official Elastic documentation.

3. Create another file named /etc/logstash/conf.d/30-elasticsearch-output.conf, and copy the following content. Then, save and exit.

     output {
       elasticsearch {
         hosts => ["localhost:9200"]
         manage_template => false
         index => "%{[@metadata][beat]}-%{[@metadata][version]}-%{+YYYY.MM.dd}"
         document_type => "%{[@metadata][type]}"
       }
     }
   Copy code

   The output rules defined in this file send the data to Elasticsearch, which runs at port 9200 on localhost. It also stores the data in an index named after the Beat used.

   Note:

   In case you want to add filters that use the Filebeat input, make sure these filters are named between the input and output configuration (between 02 and 30).

4. Start and enable the Filebeat service:

   systemctl start logstash
   systemctl enable logstash
   Copy code

Configuring Filebeat

The Elastic Stack uses lightweight data shippers (called Beats) to collect data from various sources and transport them to Logstash or Elasticsearch. In this tutorial we show how to integrate your machine with Elastic using the Filebeat Beats client.

Other Beats are available, for example: Metricbeat to collect metrics of systems and services, Packetbeat to analize network traffic or Heartbeat to monitor the availability of services.

1. Open the Filebeat configuration:

   nano /etc/filebeat/filebeat.yml
   Copy code

   Note:

   The file is written in YAML format and it is important that you respect the formatting rules when you edit the file.

2. Add the following configuration for syslog in the filebeat.inputs section of the file:

   -
   protocol.udp:
     host: "localhost:514"
   type: syslog
   Copy code

3. Search for output.elasticsearch and comment-out the lines as follows:

   [...]
   #output.elasticsearch:
     # Array of hosts to connect to.
     #hosts: ["localhost:9200"]
   [...]
   Copy code

4. Search for output.logstash and uncomment the lines as follows:

   [...]
   output.logstash:
     # The Logstash hosts
     hosts: ["localhost:5044"]
   [...]
   Copy code

5. Enable the system plugin to handle generic system log files with Filebeat. Enable the plugin:

   filebeat modules enable system
   Copy code

   Note:

   Filebeat uses different modules to parse different log files. You can keep the default configuration of the module for this tutorial. If you want to learn more about the parsing rules applied, you may check the configuration of the module located at /etc/filebeat/modules.d/system.yml.

6. Load the index template into Elasticsearch:

   filebeat setup --template -E output.logstash.enabled=false -E 'output.elasticsearch.hosts=["localhost:9200"]'
   Copy code

7. Disable the Logstash output and enable the Elasticsearch output to load the dashboards when Logstash is enabled:

   filebeat setup -e -E output.logstash.enabled=false -E output.elasticsearch.hosts=['localhost:9200'] -E setup.kibana.host=localhost:5601
   Copy code

   An output similar to the following displays:

   [...]
   Loaded machine learning job configurations
   2020-07-22T11:48:00.660Z    INFO    eslegclient/connection.go:97    elasticsearch url: http://localhost:9200
   2020-07-22T11:48:00.667Z    INFO    [esclientleg]   eslegclient/connection.go:306   Attempting to connect to Elasticsearch version 7.8.0
   2020-07-22T11:48:00.670Z    INFO    eslegclient/connection.go:97    elasticsearch url: http://localhost:9200
   2020-07-22T11:48:00.674Z    INFO    [esclientleg]   eslegclient/connection.go:306   Attempting to connect to Elasticsearch version 7.8.0
   2020-07-22T11:48:01.405Z    INFO    fileset/pipelines.go:134    Elasticsearch pipeline with ID 'filebeat-7.8.0-system-auth-pipeline' loaded
   2020-07-22T11:48:01.637Z    INFO    fileset/pipelines.go:134    Elasticsearch pipeline with ID 'filebeat-7.8.0-system-syslog-pipeline' loaded
   2020-07-22T11:48:01.637Z    INFO    cfgfile/reload.go:262   Loading of config files completed.
   2020-07-22T11:48:01.637Z    INFO    [load]  cfgfile/list.go:118 Stopping 1 runners ...
   Loaded Ingest pipelines
   Copy code

8. You can now start and enable the Filebeat service:

   systemctl start filebeat
   systemctl enable filebeat
   Copy code

9. Run the following command to verify that your Filebeat service is running:

   curl -XGET 'http://localhost:9200/filebeat-*/_search?pretty'
   Copy code

   The output should look like the following example:

   {
     "took" : 11,
     "timed_out" : false,
     "_shards" : {
       "total" : 2,
       "successful" : 2,
       "skipped" : 0,
       "failed" : 0
     },
     "hits" : {
       "total" : {
         "value" : 2058,
         "relation" : "eq"
       },
       "max_score" : 1.0,
       "hits" : [
         {
           "_index" : "filebeat-7.8.0-2020.07.22",
           "_type" : "_doc",
           "_id" : "ZIpbdnMBenM2E5SX9FAi",
           "_score" : 1.0,
           "_source" : {
             "message" : "Jul 22 11:17:44 eleastic-stack kernel: Command line: BOOT_IMAGE=/boot/vmlinuz-5.4.0-1018-kvm root=PARTUUID=fc220e13-bb33-43c7-a49a-90d85d9edc7f ro console=tty1 console=ttyS0 panic=-1",
             "@version" : "1",
             "fileset" : {
               "name" : "syslog"
             },
             "host" : {
               "containerized" : false,
               "mac" : [
                 "de:1c:4c:3e:90:3a"
               ],
               "hostname" : "eleastic-stack",
               "name" : "eleastic-stack",
               "os" : {
                 "codename" : "focal",
                 "version" : "20.04 LTS (Focal Fossa)",
                 "kernel" : "5.4.0-1018-kvm",
                 "family" : "debian",
                 "name" : "Ubuntu",
                 "platform" : "ubuntu"
               },
               "architecture" : "x86_64",
               "id" : "a4d9477d47d14c4fb551f52adb5eb810",
               "ip" : [
                 "10.65.100.115",
                 "2001:bc8:47b0:1239::1",
                 "fe80::dc1c:4cff:fe3e:903a"
               ]
             },
             "ecs" : {
               "version" : "1.5.0"
             },
             "service" : {
               "type" : "system"
             },
             "log" : {
               "offset" : 344,
               "file" : {
                 "path" : "/var/log/syslog"
               }
             },
             "input" : {
               "type" : "log"
             },
             "@timestamp" : "2020-07-22T11:49:57.578Z",
             "agent" : {
               "ephemeral_id" : "348ca814-7f48-408e-9956-d8650d74420b",
               "version" : "7.8.0",
               "type" : "filebeat",
               "hostname" : "eleastic-stack",
               "name" : "eleastic-stack",
               "id" : "76a478aa-6c78-47c8-a045-a962e89a1046"
             },
             "tags" : [
               "beats_input_codec_plain_applied"
             ],
             "event" : {
               "dataset" : "system.syslog",
               "module" : "system",
               "timezone" : "+00:00"
             }
           }
         },
   [...]
   Copy code

Exploring Kibana

The data collected by your setup is now available in Kibana.

Use the menu on the left to navigate to the Dashboard page and search for Filebeat System dashboards.

You can browse the sample dashboards included with Kibana or create your dashboards based on the metrics you want to monitor.

For more information how to use the Elastic stack, refer to the official documentation.
