Processing images and getting structured outputs with Pixtral vision model

• AI
• vision-model
• image-processing
• Pixtral
• Mistral
• structured-data

In today’s data-driven world, the ability to extract structured information from visual content is becoming increasingly valuable across various industries. From analyzing medical images to interpreting financial charts, from processing historical documents to cataloging diverse product lines, the applications are vast and varied.

Pixtral, developed by Mistral AI, is a powerful vision model capable of understanding and describing images with remarkable accuracy. By leveraging Pixtral, we can automate the process of extracting structured information from a wide range of visual inputs, including photographs, scanned documents, graphs, and more.

This tutorial will guide you through the process of using the Pixtral vision model to analyze images and automatically generate structured outputs. We’ll use Python to interact with the model and structure our data, making it easy to integrate this solution into your existing workflows. While we’ll use a product catalog as an example, the techniques demonstrated here can be adapted to various use cases across different industries.

Before you startLink to this anchor

To complete the actions presented below, you must have:

• A Scaleway account logged into the console
• A Python environment (version 3.7 or higher)
• An API key from Scaleway Identity and Access Management
• Access to a Scaleway Managed Inference endpoint with Pixtral deployed or to Scaleway Generative APIs service
• The openai and pydantic Python libraries installed

Setting up the environmentLink to this anchor

Before we dive into using Pixtral, let’s set up our Python environment and install the necessary libraries.

1. Create a new directory for your project:

   mkdir pixtral-image-processor
   cd pixtral-image-processor


2. Create a virtual environment and activate it:

   python3 -m venv venv
   source venv/bin/activate  # On Windows, use `venv\Scripts\activate`


3. Install the required libraries:

   pip install openai pydantic


Defining the data modelLink to this anchor

We’ll start by defining our data model using pydantic. This will ensure that our structured output has a consistent format and that all required fields are present.

Create a new file called models.py and add the following code:

from pydantic import BaseModel, Field
from typing import List, Optional
from datetime import date
class Dimension(BaseModel):
    length: float
    width: float
    height: float
    unit: str = Field(..., pattern="(cm|in|mm)")
class Price(BaseModel):
    amount: float
    currency: str = Field(..., pattern="[A-Z]{3}")
class Review(BaseModel):
    user_id: str
    rating: int = Field(..., ge=1, le=5)
    comment: Optional[str] = None
    date: date
class Product(BaseModel):
    id: str
    name: str
    description: str
    category: str
    subcategory: Optional[str] = None
    brand: str
    sku: str
    price: Price
    dimensions: Dimension
    weight: float
    weight_unit: str = Field(..., pattern="(kg|g|lb|oz)")
    in_stock: bool
    available_colors: List[str] = Field(..., min_items=1)
    features: List[str] = Field(..., min_items=1)
    image_urls: List[str] = Field(..., min_items=1)
    reviews: List[Review] = Field(default_factory=list)
    average_rating: Optional[float] = None
class ProductCatalog(BaseModel):
    products: List[Product]
    total_products: int
    last_updated: date

This model defines the structure for our product catalog, which we’ll use as an example of structured output from image processing.

Setting up the Pixtral clientLink to this anchor

Next, we’ll set up the client to interact with the Pixtral model. Create a new file called pixtral_client.py and add the following code:

from openai import OpenAI
import os
MODEL = "pixtral-12b-2409"
API_KEY = os.environ.get("SCALEWAY_API_KEY")
BASE_URL = os.environ.get("SCALEWAY_INFERENCE_ENDPOINT_URL")
# use https://api.scaleway.ai/v1 for Scaleway Generative APIs
client = OpenAI(
    base_url=BASE_URL,
    api_key=API_KEY
)
def get_pixtral_client():
    return client

Make sure to set the SCALEWAY_API_KEY and SCALEWAY_INFERENCE_ENDPOINT_URL environment variables with your actual API key from Scaleway IAM, and the appropriate endpoint URL for Scaleway Managed Inference or Generative APIs service.

Creating the image processorLink to this anchor

Now, let’s create the main script that will use Pixtral to analyze images and generate our structured output. Create a file called process_images.py and add the following code:

import json
from datetime import date
from pixtral_client import get_pixtral_client
from models import ProductCatalog
def process_images(image_urls):
    client = get_pixtral_client()
    prompt = """
    Extract detailed information from the provided images. Create an entry for each image.
    Include the following details for each item:
    - A descriptive name and detailed description
    - Appropriate category and subcategory
    - Realistic dimensions, weight, and pricing (if applicable)
    - At least 3 key features or characteristics
    - Any visible attributes (e.g., colors, materials)
    - Generate 2 hypothetical reviews or interpretations
    Ensure all information is consistent with what can be seen or reasonably inferred from the images.
    """
    messages = [
        {
            "role": "system",
            "content": "You are a helpful assistant. Only reply in JSON.",
        },
        {
            "role": "user",
            "content": [
                {
                    "type": "text",
                    "text": prompt
                },
                *[{"type": "image_url", "image_url": {"url": url}} for url in image_urls]
            ],
        },
    ]
    try:
        response = client.chat.completions.create(
            messages=messages,
            model=MODEL,
            response_format={
                "type": "json_schema",
                "json_schema": {
                    "strict": True,
                    "name": "Processed Image Data",
                    "schema": ProductCatalog.model_json_schema()
                }
            },
        )
        processed_data = response.choices[0].message.parsed
        structured_output = ProductCatalog(**processed_data)
        structured_output.last_updated = date.today()
        structured_output.total_products = len(structured_output.products)
        return structured_output
    except Exception as e:
        print(f"Error processing images: {e}")
        return None
def save_output_to_json(output, filename):
    with open(filename, 'w') as f:
        json.dump(output.model_dump(), f, indent=2, default=str)
if __name__ == "__main__":
    image_urls = [
        "https://picsum.photos/id/26/800/600",  # Sample image 1
        "https://picsum.photos/id/3/800/600"    # Sample image 2
    ]
    processed_output = process_images(image_urls)

    if processed_output:
        save_output_to_json(processed_output, "processed_image_data.json")
        print(f"Image processing complete. Structured data for {processed_output.total_products} items generated.")
    else:
        print("Failed to process images.")

This script does the following:

1. Imports the necessary modules and models.
2. Defines a function to process images using the Pixtral model.
3. Creates a prompt that instructs the model on how to analyze the images and what information to extract.
4. Sends the images and prompt to the Pixtral model and receives the generated structured data.
5. Validates the received data against our pydantic models.
6. Saves the generated structured output to a JSON file.

Running the image processorLink to this anchor

To use the image processor:

1. Set the environment variables for your Scaleway API key and inference endpoint URL:

   export SCALEWAY_API_KEY="your_api_key_here"
   export SCALEWAY_INFERENCE_ENDPOINT_URL="your_endpoint_url_here"


2. Run the script:

   python process_images.py


The script will process the sample images and generate a processed_image_data.json file containing the extracted structured information.

Customizing the image processorLink to this anchor

You can easily customize the image processor for your specific needs:

1. Modify the prompt in process_images.py to extract different or additional information from the images.
2. Update the models.py file to change the structure of your output data to fit your specific use case.
3. Add error handling and logging to make the script more robust for production use.

ConclusionLink to this anchor

In this tutorial, we’ve explored how to leverage Mistral’s Pixtral vision model to process images and generate structured outputs following a strict and complex JSON schema. This approach can be applied to a wide range of industries and use cases, from cataloging products to analyzing medical images, from interpreting financial charts to processing historical documents.

By combining the power of AI vision models with structured data validation, we’ve created a flexible and extensible solution that can be adapted to various image processing needs.
